All Ironman coil springs are designed to provide a safe, comfortable ride while also providing additional ground clearance.
Ironman 4x4 coil springs are CNC cold wound and bar peeled for maximum reliability and consistency, every coil spring is ‘shot-blasted’ to ensure long life, preset to its solid height and load tested to avoid spring sag.
All springs are electro-static powder-coated for a gleaming appearance. Available in raised height and perfectly matched to Ironman 4x4 Shock Absorbers.
Specifications
- Quantity Required 1
- Estimated Lift 2"
- Additional Load 440LBS-GVM
- Package Details Pair
| TOY023C | |
| Material Diameter: | 17mm |
| Free Height: | 375/370mm |
| End I/D: | 103/134mm |
| Spring Rate (N/mm): | 39 (N/mm) |
| Spring Rate (lb/in): | 223 (lb/in) |
Installation
View Coil Spring Instructions - Make:
- Toyota
- Model:
- 4Runner
- Year:
- 1990
- Year:
- 1991
- Year:
- 1992
- Year:
- 1993
- Year:
- 1994
- Year:
- 1995
- Rear Springs:
- Heavy Load
