Nitro Gas 2" Suspension Lift Kit Suited for Toyota 100 Series Land Cruiser/Lexus LX470 - Stage 1

Vehicle Fitment

Specifications

• Estimated Lift: 2"
• Package Details: Kit
• Suits Petrol Vehicles. Some middle eastern vehicles may use longer torsion bars (TOY051), check length before ordering.

Pressurized shock absorber boosts performance and adapts to a wide range of driving styles.

• NITROGEN GAS PRESSURIZED - Low pressure nitrogen gas dramatically reduces the likelihood of oil aeration and shock fade.
• 35mm TEFLON BANDED PISTON - Precision shim-stack piston specifically valved by Ironman suspension engineers, banded with teflon for smooth long life operation.
• 54mm TWIN TUBE BODY - Increased oil volume for improved cooling and endurance, Twin tube construction protects internal components from rock damage.
• 16mm – 18mm HARD CHROME PISTON ROD - Hardened and polished, volumetrically balanced to piston size.
• FLEXIBLE RUBBER BUSHES - Offers quieter operation and reduces damaging side loads from shock absorber.
• TRIPLE-LIP HIGH PRESSURE NOK SEAL - Maximum gas and oil retention ability to withstand high displacement offroad use.
• SUPPLEMENTARY WELDED MOUNTS -  Fusion welded and supplementary welded for maximum strength and reliability.
• SINGLE PIECE BILLET EYE RINGS AND STEMS - Ultra robust design prevents breakage or bending of mounts.
• VEHICLE SPECIFIC VALVING -  Every part number is specially valved for each vehicle application, this ensures the best possible ride and handling as intended by Ironman suspension engineers.
• EXTENDED TRAVEL - Suitable for standard and raised height vehicles, additional length increases wheel articulation.
• IMPACT RESISTANT STONE SHIELD - Steel or Polyethylene dust shield protects piston rod from impacts and road debris.

This Kit Includes:

• TOY050 - Front Torsion Bars (Petrol) (one set)
• Rear Coil Springs (one set)
• 12795GR - Front Shock Absorber - Nitro Gas (2)
• 12796GR - Rear Shock Absorber - Nitro Gas (2)
• BRACKET100 - Torsion Bar Reinforcement Bracket (1 Box contains right and left bracket)

Installation

 View Lower Control Arm Reinforcement Instruction Sheet

NOTE:

When installing the rear coil springs on your 100 Series Land Cruiser, first identify the part number on the spring.

The coil spring marked “D/S” (shorter coil) should be installed on the passenger's side.

The coil spring marked “N/S” (taller coil) should be installed on the driver's side.

(The taller coil should be installed on the fuel tank side.)

Installation Video:
